ITM Lifting Shoulder Eyebolt Din 580 - 24mm - 1.8T
ITM Lifting Shoulder Eyebolt Din 580 - 24mm - 1.8T
Regular price
$18.80 NZD
Regular price
Sale price
$18.80 NZD
Unit price
/
per
Taxes included.
Couldn't load pickup availability
TM9240-02240 | ITM Lifting Shoulder Eyebolt Din 580 - 24mm -1.8T
Features⢠Galvanised finish⢠Specifications batch and brand markings as per AustralianStandards requirements⢠Tested and certified to AS 2317
Specifications⢠Thread: M22⢠W.L.L (t): 1.5⢠Dimension D (mm): 22⢠Dimension D1 (mm): 40⢠Dimension D2 (mm): 40⢠Dimension D3 (mm): 16⢠Dimension H (mm): 71⢠Dimension H1 (mm): 30⢠Dimension W (mm): 72
Features⢠Galvanised finish⢠Specifications batch and brand markings as per AustralianStandards requirements⢠Tested and certified to AS 2317
Specifications⢠Thread: M22⢠W.L.L (t): 1.5⢠Dimension D (mm): 22⢠Dimension D1 (mm): 40⢠Dimension D2 (mm): 40⢠Dimension D3 (mm): 16⢠Dimension H (mm): 71⢠Dimension H1 (mm): 30⢠Dimension W (mm): 72
