ITM Lifting Shoulder Eyebolt Din 580 - 10mm. 0.23T
ITM Lifting Shoulder Eyebolt Din 580 - 10mm. 0.23T
Regular price
$2.95 NZD
Regular price
Sale price
$2.95 NZD
Unit price
/
per
Taxes included.
Couldn't load pickup availability
TM9240-02100 | ITM Lifting Shoulder Eyebolt Din 580 - 10mm.0.23T
Features⢠Galvanised finish⢠Specifications batch and brand markings as per AustralianStandards requirements⢠Tested and certified to AS 2317
Specifications⢠Thread: M10⢠W.L.L (t): 0.23⢠Dimension D (mm): 10⢠Dimension D1 (mm): 25⢠Dimension D2 (mm): 25⢠Dimension D3 (mm): 10⢠Dimension H (mm): 45⢠Dimension H1 (mm): 17⢠Dimension W (mm): 45
Features⢠Galvanised finish⢠Specifications batch and brand markings as per AustralianStandards requirements⢠Tested and certified to AS 2317
Specifications⢠Thread: M10⢠W.L.L (t): 0.23⢠Dimension D (mm): 10⢠Dimension D1 (mm): 25⢠Dimension D2 (mm): 25⢠Dimension D3 (mm): 10⢠Dimension H (mm): 45⢠Dimension H1 (mm): 17⢠Dimension W (mm): 45
